VERTYANOV SUCCESSOR BASE 4 PROGRAMMER

The VERTYANOV SUCCESSOR BASE 4 is the ultimate, next-generation professional I/O programmer engineered explicitly for advanced laptop motherboard repair. Combining a highly efficient 32-bit ARM® Cortex®-M4 RISC processor (operating at 120 MHz USB_FS) with a high-performance GoWin FPGA core, the Successor Base 4 handles reading, writing, and flashing complex Embedded Controllers (EC) and SPI FLASH memories with unmatched speed and precision.

Designed for specialized component-level technicians, this tool eliminates the need for expensive dedicated adapters when configuring multicontrollers. It also serves as a robust matrix keyboard tester and a hardware diagnostic tool, making it an indispensable asset for any modern repair lab dealing with high-end and latest-generation motherboards.

Key Features & Functionality

• Advanced Hardware Architecture: Driven by a fast ARM Cortex-M4 MCU and a highly versatile GoWin FPGA. Dual logic ensures seamless handling of hardware execution and firmware decoding.

• Dual Voltage Signal Output: Supports control signal levels of 1.8V and 3.3V, ensuring safe communication and zero risks of frying delicate modern chipsets.

• Built-in ESD Protection: Fully integrated Electrostatic Discharge (ESD) shielding protects both the programmer and the target board from static damage during hot-plugging.

• Comprehensive Multicontroller Support: Read and flash major EC brands directly through the keyboard matrix connector without desoldering.

• Integrated Keyboard Tester: Features a built-in matrix test functionality to check laptop keyboards for broken traces or stuck keys up to 50 pins.

• Future-Proof Upgrades: The internal firmware and FPGA logic are fully updatable for free, ensuring compatibility with newly released EC architectures down the road.

Supported Chipsets & Protocols

The Vertyanov Successor Base 4 offers industry-leading compatibility right out of the box:

• SPI FLASH Memory: Full high-speed read/write capabilities for main BIOS chips.

• Supported EC Brands: * ENE (e.g., KB9012, KB9010, KB9022)

  • ITE (e.g., IT8585E, IT8586E, IT8587E, IT8985E) via standard and I2C buses.

  • NUVOTON (Using a dedicated lightning-fast bootloader architecture).

  • MEC (ARC-625D core).

  • REALTEK (Full support for RTS545X controllers via expansion boards).

  • EXPLORE & I2C EEPROMs.

Technical Specifications (BASE 4 Hardware)
