UNI-T UTD2102CEX+ Digital Storage Oscilloscope- 100 MHz+ and 2 Channel
UTD2000CEX+ SERIES- Best seller
The CEX+ provides a richer trigger mode, 34 kinds of automatic parameter measurement and common mathematical operation functions, and optimizes the panel operation, which greatly improves the work efficiency and can easily cope with the measurement needs of complex signals.
- Dual Channel, 100 MHz+
- Real Time Sample Rate: 1GSa/s
- Memory Depth 64kpts, Waveform Acquisition Rate ≥5000wfms/s
- Display range 8div x16 div and has a new Auto set strategy ,which can easily cope with complex test scenarios
- HD color LCD screen display
- Multi-language optional ,With 9 languages, it can meet the needs of users in more countries
- Multi-frequency square wave optional, output standard square wave 10Hz, 100Hz, 1kHz,10kHz optional
- Various parameter measurement and waveform recording functions
FEATURES OF DSO:-
BRAND – UNI-T
PRODUCT TYPE – DIGITAL STORAGE OSCILLOSCOPE
MODEL – UTD210CEX+
TEMPERATURE – (23+-) Degree Celsius
ITEMTESTED BY TESTER – APPEARANCE TEST, FUNCTION TEST, PERFORMANCE TEST AND SAFETY TEST
PROCEDURE – WI-QIS-1264
SERIAL NO. – AD02723380689
HUMIDITY – (20/70) % RH
Specifications UTD2102CEX+
Channels 2
Bandwidth 100MHz
Sample Rate 1GS/s
Rise Time ≤3.5ns
Memory Depth 64kpts
Waveform Acquisition Rate ≥5000wfms/s
Vertical Sensitivity (V/div) 1mV/div~20V/div
Time base Range (s/div) 2ns/div~50s/div
Storage Setup, Wave, Bitmap
Trigger Modes Edge, Pulse, Alternate, Video
Interface USB OTG
Condition – Brand New
Warranty – 1 Year
No Return.
Weight – 4 kg
Please check model Number and match with your Product.
Every product proper check Before Shipping
Shipping facility available in all India.
Fast shipping
Compatible with models
