DT9205 digital multimeter is an easy to operate, accurate readings,
full-featured, compact, easy to carry, use battery-powered handheld large screen
LCD multimeter, DT9205 digital multimeter for three and a half, the table can be
used to measure DC voltage / current, AC voltage / current, resistance,
capacitance test, diode test, transistor HFE measurement and circuit off. For
engineering design, laboratory, pilot production, factory affairs, field
operations and industrial maintenance use.
MULTIMETER FEATURES :
Full-featured the wrong stalls as well as over-range protection.
Anti-burn performance better automatic shutdown function.
COMS integrated circuit, the principle of double integral A / D conversion.
Automatic zero, auto-polarity selection.
6-off test high quality buzzer sound and light-emitting diode indication.
Parameter indicators.
Specification
Product Name
Digital Multimeter
AC Voltage (V) : 2V, 20V, 200V, 750V
DC Voltage (V) : 200mV, 2V, 20V, 200V,1000V
AC Current (A) : 2mA, 200mA, 20A
DC Current (A) : 20uA, 2mA, 200mA,20A
Resistance (Ohm) : 200, 2k, 20k, 200k, 2M, 20M, 200M
Capacitance (F) : 20nF, 2uF, 20uF, 200uF
Other Measuring Function : Diode, hFE,
Power By 1 x 9V 6F22 battery (not included)
Main Color : Black, Orange
Material : Plastic & Metal
Test Leads Total Length : 70cm/ 27.6″
Multimeter Size : 20.4 x 9.6 x 3.5cm/ 8.03″ x 3.7″ x 1.4″ (L*W*T)
Note: Due to the difference
between different monitors, the picture may not reflect the actual color of the
item.
Condition – Brand New
Warranty – 30 Days
No Return .
Please check model Number and match with your Product.
Every product proper check Before Shipping
Shipping facility available in all India.
Fast shipping
Compatible with models
